| Rahmen | Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 180 kg |
|---|---|
| Gabel | Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 180 kg |
| Gewicht | 27,9 kg (61,5 lb.) |
| Zul. Gesamtgewicht | 180kg |
| Schalthebel | Shimano Nexus INTER-5E |
|---|---|
| Kette | Gates Carbon Drive CDX belt |
| Kasette | Gates CDX, precision CNC machined cog |
| Bremshebel | Shimano, hydraulic disc |
| Bremse vorne | Shimano, hydraulic disc, 180 mm rotor |
| Bremse hinten | Shimano, hydraulic disc, 160 mm rotor |
| Motor | Bosch Performance, 340% Assist, 75 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
|---|---|
| Akku | Bosch PowerPack 545 |
| Ladegerät | 220V, 4A (EU); 100-240V, 4A (US) |
| Display | Bosch Intuvia 100 w/ LED remote, 4 mode selectable, walk assist, connectivity with Bosch eBike Flow app, electronic bike lock |
| Kurbelgarnitur | Tern HSD custom, Gates CDX CNC machined beltring |
| Laufradsatz | Tern Atlas H, wide 35 mm |
|---|---|
| Reifen vorne | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
| Reifen hinten | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
| Nabe (Vorne) | Novatec, Thru-axle, sealed bearings |
| Nabe (Hinten) | Shimano Nexus INTER-5E |
| Pedale | Urban with non-slip surface |
| Lenker | Tern Sweep, 6061-AL, Tern Andros adapted |
| Vorbau | Tern Andros, adjustable, forged construction, patented technology |
| Griffe | Ergon |
| Seitenständer | Ursus, rear mount |
| Steuersatz | Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated |
| Sattel | Tern Upright by Velo |
| Sattelstütze | Tern Telescope, 34.9/30.9 mm, 2014-AL |
| Gepäckträger | Atlas H rack, Atlas Rack Mount, 6 point mounting, 80 kg capacity |
| Schutzbleche | SKS, stainless hardware |
| Scheinwerfer | Tern Valo Direct, 190 lumens |
| Rücklicht | Herrmans H-Trace, for eBike |
